Features:
• Compliant with 802.11b / 802.11g / 802.11n standard
• Supports Wi-Fi Protected Setup (WPS)
• Farther coverage, less dead space and higher throughput with 802.11n technology
• Supports 64/128-bit WEP, WPA (TKIP with IEEE 802.1x), WPA2 (AES with IEEE 802.1x) and functions for high level of security
• Accesses Private LAN Servers from Public Networks
• AP / Station-Infrastructure / Bridge (Point to Point, Point to Multi-Point, WDS) modes supported
• Equipped with four LAN ports (10/100/1000M) and one WAN port (10/100/1000M), Auto-MDI / MDI-X supported
• Supports DHCP Server
• Dynamic / Static / PPPoE / PPTP / L2TP IP allocation
• MAC/IP filter access control, URL blocking
• SPI firewall + DoS prevention and protection
• Support Virtual Server, ALG, DMZ and UPnP for various networking applications
• Support QoS mechanism for efficiently prioritizing the various type of traffics
• System status monitoring includes Active DHCP Client, Security Log and Device/Connection Status
• Remote Management allows configuration and upgrade from a remote site
• User-friendly Web-Based GUI for configuration and management purposes
• Intelligent configuration wizard with auto WAN detection
Technical Specifications:
• Standart: IEEE 802.11b/g , 802.11n 2.0
• Signal Type: 11b mode: DSSS, 11g mode: OFDM, 11n mode: OFDM, MIMO
• Modulation 11b mode: CCK, DQPSK, DBPSK, 11g mode: 64 QAM, 16 QAM, QPSK, BPSK, 11n mode: 64 QAM, 16 QAM, QPSK, BPSK
• WAN Port: 1 x 10/100/1000Base-T, Auto-MDI/MDI-X
• LAN Port: 4 x 10/100/1000Base-T, Auto-MDI/MDI-X
• Antennas: 2 x 3dBi detachable antenna
• Data Encryption: 64 bit / 128 bit WEP, WPA-PSK, WPA2-AES, WPA, WPA2
• Frequency: 2.4GHz - 2.484GHz
• Data Rate: IEEE 802.11b: 1/2/5.5/11Mbps, IEEE 802.11g: 6/9/12/18/24/36/48/54Mbps, IEEE 802.11n: up to 300Mbps
• TX Output Power: 11b mode: 17dBm, 11g mode: 14dBm, 11n mode: 14dBm
• Receive Sensitivity; 802.11n (20MHZ): Range -72dBm ~ 87dBm, 802.11n (40MHZ):Range -68dBm ~ 87dBm,802.11g :Range -72dBm ~ 91dBm, Error Rate = 10% at room temperature, 802.11b:Range -89dBm ~ 91dBm, Error Rate = 8% at room temperature
• Range Cover: Per cell coverage up to 1-300 meters
• WPS: Wi-Fi Protected Setup
• WMM: Wi-Fi Multimedia
• Ethernet WAN PPPoE, DHCP client, Static IP, PPTP, L2TP
• WAN Connection: Auto-reconnect, dial-on-demand, manually
• One-to-Many NAT: Virtual server, special application, DMZ, Super DMZ(IP pass-through)
• NAT Session: Support 20000 NAT sessions
• Routing Protocol: Static route, dynamic route (RIP v1/v2)
• SPI Firewall: IP/Server filter, URL blocking, MAC control
• DoS Protection: DoS(Deny of Service) detection and protection
• Management: SNMP, UPnP IGD, syslog, DDNS
• Administration: Web-based UI, remote login, backup/restore setting
• Temperature: Operating: 0 ~ 40 Degree C
• Storage: -10 ~ 70 Degree C
• Humidity: Operating: 10 ~ 90% Non-Condensing
• Storage: 0 ~ 95% Non-Condensing
• Dimension (W x D x H) 186 x 111 x 27 mm
• Weight: 270g
• Power Requirement: 12V DC, 1A
