Key Features
Industrial Compliant Wireless LAN & LAN
• 300Mbps wireless transmission rate with MIMO technology
• IEEE 802.11n, 802.11b/g standard compliant
• Equipped with 10/100Mbps RJ-45 Ports for LAN/ WAN, Auto MDI/ MDI-X supported
Fixed-network Broadband Router
• Supported connection types: Dynamic IP / Static IP / PPPoE / PPTP / L2TP
• Supports Static Routing, IGMP Proxy
• Supports multiple sessions SIP ALG, IPSec, L2TP and PPTP VPN pass-through
• Supports DMZ, Port Forwarding and Port Triggering for various networking applications
• Supports DHCP Server, UPnP, Planet Dynamic DNS
Wireless Network Range Extender
• Multiple Wireless Modes: AP, WDS, Repeater, Universal Repeater, Client
• Supports Multiple SSID to allow users to access different networks through a single AP
• Supports WMM (Wi-Fi Multimedia), Wireless QoS
• Supports IAPP (Inter Access Point Protocol), Wireless Roaming
Secure Network Connection
• Advanced security: 64/128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK (TKIP/AES)
• Built-in NAT firewall features, with SPI function to protect against DoS attacks
• Supports IP / MAC / URL / DNS Filtering
Easy Installation & Management
• Web-Based UI and Quick Setup Wizard for easy configuration
• Remote Management allows configuration from a remote site
• System status monitoring includes DHCP Client, System Log
Flexible Usage & Compact Design
• Hardware switchable operation modes: AP / Repeater / Client
• Easily extends secure wireless network by One-touch Wi-Fi Protected Setup (WPS)
• Quickly repeat Wi-Fi signal to anywhere through its Stylish Wall-Plug Design
Specification:
• Interface: LAN/WAN: 1 x 10/100Mbps Auto MDI/MDI-X RJ45 port
• Antenna: Gain: 2 x Internal 2dBi Antenna Orientation: Horizontal and Vertical
• Button / Switch: Mode Selection Switch (AP / Repeater / Client) , WPS Button, Reset button Push about 3~6 seconds to reset to factory default settings
• LED Indicators: PWR, WPS, Ethernet, WLAN
• Material: Plastic
• Dimension: (W x D x H) 55 x 75 x 40 mm
• Weight: 80g (gross weight)
• Power Requirement: 100~240VAC
• Plug Type: EU / US
• Power Consumption: On-state: 2.1W, Low power state: 1.5W
Wireless interface Specification
• Standard: Compliant with IEEE 802.11b/g/n
• Frequency Band: 2.4~2.4835GHz
• Extend Frequency: DSSS
• Modulation Type: DBPSK, DQPSK, QPSK, CCK and OFDM (BPSK / QPSK / 16-QAM / 64-QAM)
• Data Transmission Rates: 802.11n(40MHz): 270/243/216/162/108/81/54/27Mbps, 135/121.5/108/81/54/40.5/27/13.5Mbps (Dynamic), 802.11n(20MHz): 130/117/104/78/52/39/26/13Mbps, 65/58.5/52/39/26/19.5/13/6.5Mbps (Dynamic), 802.11g: 54/48/36/24/18/12/9/6Mbps (Dynamic), 802.11b: 11/5.5/2/1Mbps (Dynamic)
• Transmission Distance: Indoor up to 100m., Outdoor up to 300m (Depends on the environment)
• Channel: America / FCC: 2.412~2.462GHz (11 Channels), Europe / ETSI: 2.412~2.472GHz (13 Channels), Japan / TELEC: 2.412~2.484GHz (14 Channels)
• Channel Width: 20 / 40MHz
• Max. RF Power: 802.11b: 17±1.5dBm, 802.11g: 14±1.5dBm, 802.11n (20MHz): 14±1.5dBm, 802.11n (40MHz): 14±1.5dBm
• Receive Sensitivity: 802.11b: -92dBm @ 1Mbps; -85dBm @ 11Mbps, PER < 8%, 802.11g: -88dBm @ 6Mbps; -73dBm @ 54Mbps, PER <10%, 802.11n: -90dBm @ MCS8; -70dBm @ MCS15, PER <10%
Software Features
• Operation Mode: AP/Router, Repeater, Client (Switchable by Hardware)
• Wireless Mode: Universal Repeater(AP+Client), Repeater(WDS+AP), WDS PTMP(Point to Multipoint), WDS PTP(Point to Point), Client, AP(Access Point)
• Encryption Security: WEP (64/128-bit), WPA / WPA2 (TKIP/AES), WPA-PSK / WPA2-PSK (TKIP/AES)
• Wireless Security: Provides wireless LAN ACL (Access Control List) filtering, Wireless MAC address filtering up to 16 entries, Supports WPS (Wi-Fi Protected Setup), Enable / Disable SSID Broadcast
• Wireless Advanced: WMM (Wi-Fi Multimedia): 802.11e Wireless QoS, Multiple SSID: up to 4, Wireless Isolation: Supports Wireless Isolation, IAPP (Inter Access Point Protocol): 802.11f Wireless Roaming, Provides Wireless Statistics
• Max. Clients: Wire: 253, Wireless: 32
• Internet Connection Type: Shares data and Internet access for users, supporting the following internet access: Dynamic IP, PPTP Static IP, L2TP, PPPoE
• Firewall: NAT firewall with SPI (Stateful Packet Inspection), Built-in NAT server supporting Port Forwarding, Port Triggering, and DMZ, Built-in firewall with IP address / MAC address / Port / URL filtering, Supports ICMP-FLOOD, UDP-FLOOD, TCP-SYN-FLOOD filter, DoS protection
• Routing Protocol: Static Routing
• VPN Pass-through: SIP ALG, PPTP, L2TP, IPSec
• LAN: Built-in DHCP server supporting static IP address distributing: Supports UPnP, Dynamic DNS, Supports IGMP Proxy
• System Management: Web-Based (HTTP) management interface, SNTP time synchronize, Easy firmware upgrade
• Standards Conformance: IEEE Standards IEEE 802.11n (2T2R, up to 300Mbps), IEEE 802.11g, IEEE 802.11b, IEEE 802.11i, IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3x Flow Control
• Others Protocols and Standards: CSMA / CA, CSMA / CD, TCP / IP, DHCP, ICMP, NAT, PPPoE, SNTP
Environment & Certification
• Temperature: Operating: 0 ~ 45 Degree C, Storage: -20 ~ 70 Degree C
• Humidity: Operating: 10 ~ 90% (Non-Condensing), Storage: 5 ~ 90% (Non-Condensing)
• Regulatory: CE, RoHS
