Features:
• Complies with IEEE 802.11ac (draft 2.0) and IEEE 802.11a/b/g/n standards
• 1 x 10/100/1000Base-T Port with 1-port PoE (PD, Powered Device)
• IEEE 802.3at Power over Ethernet design
RF Interface Characteristics
• Features 2.4GHz (802.11b/g/n) and 5GHz (802.11a/n/ac) concurrent dual band for more efficiency of carrying high load traffic
• 2T2R MIMO technology for enhanced throughput and coverage
• Provides multiple adjustable transmit power control
• High speed up to 1.2Gbps (300Mbps for 2.4GHz + 867Mbps for 5GHz) wireless data rate
Comprehensive Wireless Advanced Features
• Multiple Wireless Modes: AP, Client, WDS PtP/ PtMP, WDS Repeater, Universal Repeater
• Supports up to 10 multiple-SSIDs (2.4GHz+5GHz) to allow users to access different networks through a single AP
• Supports WMM (Wi-Fi Multimedia) and wireless QoS to enhance the efficiency of multimedia application
• Supports IAPP (Inter Access Point Protocol) and wireless roaming to enable clients to roam across different wireless networks
• Supports 5-level Transmitting Power Control to adapt various environments
• Supports wireless schedule to automatically enable or disable the wireless function based on predefined schedule
Secure Network Connection
• Advanced security: 64/128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK (TKIP/AES encryption) and 802.1x Radius Authentication
• Supports MAC address filtering
Easy Installation & Management
• Flexible deployment with standard 802.3at PoE/ PD supported
• Web-based UI and Quick Setup Wizard for easy configuration
• Remote Management allows configuration from a remote site
• SNMP-based management interface
• System status monitoring includes DHCP Client and System Log
Technical Specifications:
• Interfaces LAN 1 x 10/100/1000Base-T RJ45 port
• Auto-negotiation and Auto MDI/MDI-X
• Antennas Gain 2 x 2.4GHz 2.5dBi PCB antenna
• 2 x 5GHz 4dBi PCB antenna
• Reset Button Reset button on the top cover
• Press over 7 seconds to reset the device to factory default
• LED Indicators PWR
• Allow LED to turn off via software control
• Material Plastic
• Dimensions (F x H) 194 x 49 mm
• Weight 300 ±5g
• Power Requirements 802.3at PoE, 48-56V DC input
• Power Consumption 20W (max.)
• Mounting Ceiling Mount
• Wireless Interface Specifications
• Standard IEEE 802.11ac (Draft 2.0) 5GHz
• IEEE 802.11a/n 5GHz
• IEEE 802.11b/g/n 2.4GHz
• Antenna Structure 802.11ac: 2T2R MU-MIMO
• 802.11n: 2T2R MIMO
• Modulation DSSS
• Data Modulation 802.11ac: OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM)
• 802.11a/g/n: OFDM (BPSK / QPSK / 16QAM / 64QAM)
• 802.11b: DSSS (DBPSK / DQPSK / CCK)
• Band Mode 2.4GHz / 5GHz concurrent mode
• Frequency Range 2.4GHz: America/ FCC: 2.412~2.462GHz
• Europe/ ETSI: 2.412~2.484GHz
• 5GHz: America/ FCC: 5.180~5.240GHz, 5.725~5.850GHz
• Europe/ ETSI: 5.180~5.240GHz
• Operating Channels 2.4GHz: America/ FCC: 1~11
• Europe/ ETSI: 1~13
• 5GHz: America/ FCC: 36, 40, 44, 48, 149, 153, 157, 161, 165
• Europe/ ETSI: 36, 40, 44, 48
• 5GHz channel list will vary in different countries according to their regulations.
• Channel Width 802.11ac: 20/40/80MHz 02.11n: 20/40MHz
• Data Transmission Rates 802.11ac (VHT20, Nss2-MCS8): Up to 173.3Mbps
• 802.11ac (VHT40, Nss2-MCS9): Up to 400Mbps
• 802.11ac (VHT80, Nss2-MCS9): Up to 867Mbps
• 802.11n (HT40): 270/243/216/162/108/81/54/27Mbps 135/121.5/108/81/54/40.5/27/13.5Mbps (dynamic)
• 802.11n (HT20): 130/117/104/78/52/39/26/13Mbps 65/58.5/52/39/26/19.5/13/6.5Mbps (dynamic)
• 802.11g: 54/48/36/24/18/12/9/6Mbps (dynamic)
• 802.11b: 11/5.5/2/1Mbps (dynamic)
• Transmission Distance 802.11ac (draft): up to 30m
• 802.11n: up to 70m
• 802.11g: up to 30m
• The estimated transmission distance is based on the theory. The actual distance will vary in different environments.
• Max. RF Power 5GHz:
• 802.11ac (VHT20): 15.5dBm
• 802.11ac (VHT40): 15.5dBm
• 802.11ac (VHT80): 15.5dBm
• 802.11n (HT20): 15.5dBm
• 802.11n (HT40): 15.5dBm
• 802.11a: 15.5dBm
2.4GHz:
• 802.11n: 17 ±2.5dBm
• 802.11b/g: 20 ±2.5dBm
Receive Sensitivity 5GHz:
• 802.11ac (VHT20): -91dBm @ Nss1-MCS0, -64dBm @ Nss2-MCS8
• 802.11ac (VHT40): -89dBm @ Nss1-MCS0, -59dBm @ Nss2-MCS9
• 802.11ac (VHT80): -86dBm @ Nss1-MCS0, -56dBm @ Nss2-MCS9
• 802.11n (HT20): -92dBm @ MCS0, -71dBm @ MCS7
• 802.11n (HT40): -89dBm @ MCS0, -66dBm @ MCS15
• 802.11a: -93 @ 6Mbps, -75dBm @ 54Mbps
2.4GHz:
• 802.11n 20MHz (MCS7): -69dBm @10% PER
• 802.11n 40MHz (MCS15): -66dBm @10% PER
• 802.11g (54Mbps): -74dBm @10% PER
• 802.11b (11Mbps): -88dBm @10% PER
Software Features
• Wireless Mode, Universal Repeater (AP+Client)
• Repeater (WDS+AP)
• AP (Access Point)
• WDS PTP (Point to Point)
• WDS PTMP (Point to Multipoint)
• Client
• Encryption Security, WEP (64/128-bit) encryption security
• WPA / WPA2 (TKIP/AES)
• WPA-PSK / WPA2-PSK (TKIP/AES)
• Wireless Security Provides wireless LAN ACL (Access Control List) filtering
• Wireless MAC address filtering
• Supports WPS (Wi-Fi Protected Setup)
• Enable/ Disable SSID Broadcast
• Wireless Advanced WMM (Wi-Fi Multimedia): 802.11e Wireless QoS
• Multiple SSID: up to 5 at 2.4GHz and 5GHz, respectively
• Wireless Isolation: Enables to isolate each connected wireless client from communicating with each other
• IAPP (Inter Access Point Protocol): 802.11f Wireless Roaming
• Provides Wireless Statistics
• Max. Clients Wire: 253
• 2.4GHz Wireless: 32
• 5GHz Wireless: 32
• LAN Built-in DHCP server supporting static IP address distributing
• Supports UPnP
• Supports 802.1d Spanning Tree
• System Management Web-based (HTTP) management interface
• SNTP time synchronize
• Easy firmware upgrade
• Supports Scheduling Reboot
• Supports Smart Discovery Utility
Standards Conformance
• IEEE Standards IEEE 802.11ac (Draft 2.0, 2T2R, up to 867Mbps)
• IEEE 802.11n (2T2R, up to 300Mbps)
• IEEE 802.11g
• IEEE 802.11b
• IEEE 802.11i
• IEEE 802.3 10Base-T
• IEEE 802.3u 100Base-TX
• IEEE 802.3ab 1000Base-T
• IEEE 802.3x Flow Control
• Other Protocols and Standards CSMA/CA, CSMA/CD, TCP/IP, DHCP, ICMP, SNTP
Environment & Certification
• Temperature Operating: 0 ~ 50 degrees C
• Storage: -40 ~ 70 degrees C
• Humidity Operating: 10 ~ 90% (non-condensing)
• Storage: 5 ~ 90% (non-condensing)
• Regulatory FCC Part 15B & 15C, IC, RoHS
