Features:
• Complies with IEEE 802.3af Power over Ethernet
• Extends the range of PoE by an additional 100 meters (328ft.)
• Forwards both Ethernet data and PoE power to remote devices
• Automatically detects and protects PoE equipment from being damaged by incorrect installation
• Multiple units, daisy-chain installation support
• No external power cable required for installation
• Compact size, wall-mountable design
• Plug-and-Play
Technical Specifications:
• LAN IN: 1 x 10/100Base-TX Ethernet with IEEE 802.3af PoE “Data + DC” in, Auto MDI/MDI-X, auto-negotiation RJ-45 connector
• LAN OUT: 1 x 10/100Base-TX Ethernet with IEEE 802.3af PoE “Data + DC” out, Auto MDI/MDI-X, auto-negotiation RJ-45 connector
• PoE Standard: IEEE 802.3af Power over Ethernet
• PoE Power Supply Type: Mid-Span / Type B
• PoE Power Output: 48V DC, 270mA, Max. 13Watts
• Power Pin Assignment: 4/5(+), 7/8(-)
• Maximum Distance: Class 1 (3.8 watts): 300m, Class 2 (6.5 watts): 300m, Class 3 (12.9 watts): 200m, Non-PoE (Data): 300m
• Hardware Version: Version 2
• Data Rate: 10/100Mbps
• Switch Architecture: Store-and-Forward
• Switch Throughput: 148810pps@64Bytes
• Latency: 7.840µs
• Maximum Frame Size: 1552Bytes
• Flow Control: Back pressure for half-duplex, IEEE 802.3x pause frame for full-duplex
• LED Indicators: 1 x PoE IN (Green), 1 x LAN Data (Green), 1 x PoE OUT (Green)
• Protection: ESD(Ethernet): 6KV, Surge (EFT for power) : 6KV
• Regulation Compliance: FCC Part 15 Class A, CE
• Standard Compliance: IEEE 802.3 10Base-T Ethernet, IEEE 802.3u 10/100Base-TX Fast Ethernet, IEEE 802.3af Power over Ethernet PSE / Mid-Span, IEEE 802.3af Power over Ethernet PD / Mid-Span, IEEE 802.3x Flow Control
• Dimensions (W x D x H): 94 x 70 x 26 mm
• Weight: 215g
• Power Requirements: IEEE 802.3af compliant with voltage within 44V-56V DC
• Power Consumption: 2 watts (maximum)
• Mechanical: Metal / wall mountable and optional DIN-rail kit for installation
• Cable: TIA / EIA-568, Category 5/5e cable
• Operating: Temperature: 0 ~ 50 degrees C, Relative Humidity: 0 ~ 95% (non-condensing)
• Storage Temperature: -10 ~ 85 degrees C , Relative Humidity: 5 ~ 95% (non-condensing)
