Features:
• 2-Port 10/100/1000Mbps RJ-45 interfaces
- 1-Port Data + Power output
- 1-Port Data + 802.3af/at Power input
• Complies with IEEE 802.3af/at Power over Ethernet PD
• Non-IEEE 802.3af/at injector port
• 1 DC 12V/19V/24V DIP switch
• Power Output Pin: 4/5(+), 7/8(-)
• Metal case
• LED indicators for PoE-In LED and 12V/19V/24V Output Voltage LED
• IEEE 802.3 10Base-T
• IEEE 802.3u 100Base-TX
• IEEE 802.3ab 1000Base-T
• IEEE 802.3at High Power over Ethernet
• IEEE 802.3af Power over Ethernet
• FCC Part 15 Class A, CE
Technical Specifications:
• Interface: PoE In Port: 1 x IEEE 802.3af/at RJ-45 STP / PD, Passive PoE Out Port: 1 x non-802.3af/at RJ-45 STP / PSE
• LED Indicator: System, PoE In (Green), Passive PoE Out ,12V (Green),19V (Green), 24V (Green)
• Network Cable: 10Base-T: 2-Pair UTP Cat. 3, 4, 5, 100Base-TX: 2-Pair UTP Cat. 3, 4, 5, 1000Base-T: 2-Pair UTP Cat. 5, 5e, 6 , EIA/TIA-568 100-ohm STP
• DIP Switch: 12V/19V/24V DC Output Voltage
• Power Input: IEEE 802.3af/at Power over Ethernet End-Span / Mid-Span Class 4 PD
• Power Output: Maximum Passive PoE , 12V DC, 0.7A, 19V DC, 0.7A, 24V DC, 0.7A
• Power Output Pin Assignment: 4/5(+), 7/8(-)
• Data Rate: 10/100/1000Mbps
• Maximum Distance: Up to 100meters (Including POE-165S)
• Dimensions (W x D x H) 94 x 70.3 x 26.2 mm
• Weight: 182g
• Number of devices that can be powered: 1
• Operating Temperature -40 ~ 75 degrees C
• Storage Temperature: -40 ~ 85 degrees C
• Operating Humidity 5 ~ 90%, Relative Humidity, non-condensing
• Storage Humidity: 5 ~ 90%, Relative Humidity, non-condensing
• Compliant PLANET Outdoor Wireless Devices: 2.4GHz WNAP-6306 (v2) @ 12V, 5GHz WNAP-7206 @ 12V, WNAP-7300 @ 19V/24V, WNAP-7320 @ 12V/19V/24V
• Standards Compliance: IEEE 802.3 10Base-T Ethernet, IEEE 802.3u 100Base-TX Fast Ethernet, IEEE 802.3ab 1000Base-T Gigabit Ethernet , IEEE 802.3at High Power over Ethernet , IEEE 802.3af Power over Ethernet
• Regulation Compliance: FCC Part 15 Class A, CE
