Technical Specifications:
• Interface "Data" Input Ports:12 x RJ-45 STP
• "Data + Power" Output Ports:12 x RJ-45 STP
• Management Port:1 x RJ-45; 10/100Base-TX, auto-negotiation, auto-MDI / MDIX
• LED System: Power x 1 (Green)
• Management Port x2: 10/100 (Green / Orange)
• Per PoE Port: PoE in Use x 1 (Green)
• Network Cable 10Base-T: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328ft)
• 100Base-TX: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328ft)
• EIA / TIA- 568 100-ohm STP (100m)
• Dimension (W x D x H) 440 x 200 x 44 mm (1U height)
• Weight 2.7kg
• Power Requirement 100-240V AC, 50/60 Hz
• Power Consumption 130 watts max.
• Operating Temperature 0 ~ 50 Degree C
• Storage Temperature -40 ~ 70 Degree C
• Humidity 5 ~ 95% (Non-condensing)
• Cooling Fan x 1
• PoE Standard IEEE 802.3af Power over Ethernet / Mid-Span PSE
• PoE Power supply Type Mid-Span
• PoE Power Output Per Port 48V DC, 350mA . Max. 15.4 watts
• Power Pin Assignment 4/5(+), 7/8(-)
• Power Budget 110 Watts
• Management Interface Web, PLANET Smart Discovery Lite
• PoE Management Power Limit by Priority and Total Limit
• Per port power enable / disable
• Power feeding priority
• Current usage and status
• Total power consumption
• Management Feature System / Management functions setup
• Web firmware upgrade
• SNMP Trap for alarm notification of events
• Standards Compliance IEEE 802.3 10Base-T Ethernet
• IEEE 802.3u 100Base-TX Fast Ethernet
• IEEE 802.3af Power over Ethernet
• Regulation Compliance FCC Part 15 Class A, CE
