Technical Specifications:
• Network Connector 8-Port RJ-45 for 10/100Base-TX
• PoE Inject Port 4-Port with PoE injector function, Port-1 to Port-4
• LED Display One power,
• 1-4 port PoE in-use, LNK / ACT
• 1-8 port LNK / ACT
• Switch Architecture Store and Forward switch architecture
• Switch Fabric 1.6Gbps
• MAC Address 1K MAC address table with Auto learning function
• Throughput 1.19Mpps
• Power AC 100~240V, 50/60Hz
• Power Consumption Max. 65 watts / 221 BTU
• Dimension (W x D x H) 217 x 135 x 43 mm
• Weight 1.0 kg
• PoE Standard IEEE 802.3af Power over Ethernet / PSE
• PoE Power Supply Type End-Span
• PoE Power Output Per Port 48V DC, 350mA . Max. 15.4 watts
• Power Pin Assignment 1/2(+), 3/6(-)
• PoE Power Budget 55 watts
• EMI Safety FCC Class A, CE
• Operating environment 0~40 degree C, 10%~95%RH
• Storage environment -40 ~70 degree C, 95% RH
• Operating Humidity 5% to 90% , relative humidity, non-condensing
• Storage Humidity 5% to 90% , relative humidity, non-condensing
• Standard Compliance IEEE 802.3 Ethernet
• IEEE 802.3u Fast Ethernet
• IEEE 802.3x Flow Control
• IEEE 802.3af Power over Ethernet
