Interface
• 16-Port 10/100/1000Mbps Gigabit Ethernet RJ-45 ports
• Each port supports 52V DC power to PoE Powered Device
Power over Ethernet
• Complies with IEEE 802.3af / IEEE 802.3at Power over Ethernet
• Up to 16 IEEE 802.3af / IEEE 802.3at devices powered
• Supports PoE Power up to 30 Watts for each PoE port
• Auto detect powered device (PD)
• Circuit protection prevents power interference between ports
• Remote power feeding up to 100m
Switching
• Hardware based 10/100/1000Mbps Auto-Negotiation and Auto MDI/MDI-X
• Flow control for Full Duplex operation and back pressure for Half Duplex operation
• Integrates address look-up engine, supporting 8K absolute MAC addresses
• 9K Jumbo Frame supports at all speed (10/100/1000Mbps)
• Automatic address learning and address aging
• Supports Pre-Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)
Hardware
• 19-inch desktop size, 1U height
• LED indicators for PoE ready and PoE activity
• Ethernet Link Energy-Saving technology
- Link down power saving
- Intelligent scales power based on cable length
Hardware Specification
• Network Port: 16 10/100/1000Base-T Auto-MDI/MDI-X RJ-45 ports
• PoE Inject Port: 16-Port with 802.3af / 802.3at PoE injector function
• LED Display System: Power (Green), PoE Ethernet Interfaces, PoE In-Use (Orange), 10/100/1000Base-T Ports,1000 (LNK/ACT, Green), 10/100 (LNK/ACT, Orange)
• Switch Architecture: Store and Forward switch architecture
• MAC Address: 8K MAC address table with Auto learning function
• Switch Fabric: 32Gbps
• Switch Throughput: 23.8Mpps@64Bytes
• Jumbo Packet Size: 9K Bytes
• Flow Control: Back pressure for Half-Duplex. IEEE 802.3x Pause Frame for Full-Duplex
• Power Requirement: AC 100~240V, 50/60Hz, 3.5A max.
• Power Consumption: Max. 260 Watts / 885 BTU
• Dimension: (W x D x H) 445 x 207 x 45 mm (1U height)
• Weight: 2.54kg
Power over Ethernet
• PoE Standard: IEEE 802.3af Power over Ethernet / PSE, IEEE 802.3at Enhancement Power over Ethernet / PSE
• PoE Power Output: Per Port 52V DC, 300mA. Max. 15.4 Watts (IEEE 802.3af)
• Per Port: 52V DC, 590mA. Max. 30 Watts (IEEE 802.3at)
• PoE Power Budget: 220 Watts
• Number of PD, 7Watts|: 16
• Number of PD, 15.4Watts: 14
• Number of PD, 30.8Watts: 7
Environment
• Operating environment: 0 ~ 50 Degree C
• Storage environment: -40 ~ 70 Degree C
• Operating Humidity: 5 ~ 95%, relative humidity, non-condensing
• Storage Humidity: 5 ~ 95%, relative humidity, non-condensing
Standard Conformance
• Standard Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az
• Regulation Compliance: FCC Class A, CE
