Features:
•8-Port 10/100/1000Mbps Gigabit Ethernet ports
• 4-Port supports 48V DC power to PoE Powered Device
• Complies with IEEE 802.3af Power over Ethernet End-Span PSE
• Up to 4 IEEE 802.3af devices powered
• Supports PoE Power up to 15.4 watts for each PoE port
• Auto detect powered device (PD)
• Circuit protection prevents power interference between ports
• Remote power feeding up to 100m
• Hardware based 10/100/1000Mbps Auto-negotiation and Auto MDI/MDI-X
• Flow control for full duplex operation and back pressure for half duplex operation
• Integrates address look-up engine, supporting 8K absolute MAC addresses
• 9K Jumbo Frame supports at all speed (10/100/1000Mbps)
• Automatic address learning and address aging
• 10-inch desktop size, rack mountable; 1U height
• LED indicators for PoE ready and PoE activity
• Optional Rack Ear Accessories Kit for 10-inch cabinet (RKE-10A) and 19-inch cabinet (RKE-10B)
• 1 silent fan to provide stable and efficient power performance
• Energy-Saving technology
• Link down power saving
• Intelligent scales power based on cable length
Technical Specifications:
• Network Connector: 8-Port RJ-45 for 10/100/1000Base-T
• PoE Inject Port: 4-Port with 802.3af PoE injector function, Port-1 to Port-4
• LED Display 1 Power , 1 Fan Alert
• 1-4 port PoE in-use
• 1-8 port Speed, LNK/ACT
• Switch Architecture: Store and Forward switch architecture
• MAC Address: 8K MAC address table with auto learning function
• Switch Fabric: 16Gbps
• Switch Throughput: 11.9Mpps
• Jumbo Packet Size: 9K Bytes
• Power Requirements: AC 100~240V, 50/60Hz, 1.5A
• Power Consumption: Max. 65 watts / 221 BTU
• Dimensions (W x D x H) 217 x 135 x 43 mm
• Weight: 890g
• PoE Standard: IEEE 802.3af Power over Ethernet / PSE
• PoE Power Supply Type End-Span
• PoE Power Output: Per Port 48V DC, 350mA . Max. 15.4 watts
• Power Pin Assignment: 1/2(+), 3/6(-)
• PoE Power Budget: 55 watts
• EMI Safety: FCC Class A, CE
• Operating Temperature: 0 ~ 50 degrees C
• Storage Temperature: -40 ~ 70 degrees C
• Operating Humidity: 5 ~ 95%, relative humidity, non-condensing
• Storage Humidity: 5 ~ 95%, relative humidity, non-condensing
• Standard Compliance: IEEE 802.3: Ethernet
• IEEE 802.3u: Fast Ethernet
• IEEE 802.3ab: Gigabit Ethernet
• IEEE 802.3x: Flow Control
• IEEE 802.3af: Power over Ethernet
