Features:
• Five 10/100Mbps Fast Ethernet ports
• Four ports support 56V DC power to PoE Powered Device
• One 10/100Mbps uplink port
• Complies with IEEE 802.3at / af Power over Ethernet Mid-Span PSE
• Up to 4 IEEE 802.3at / af devices powered
• Supports PoE Power up to 30 watts for each PoE port
• 60-watt PoE Budget
• Auto detects powered device (PD)
• Circuit protection prevents power interference between ports
• Remote power feeding up to 100m
• Hardware based 10/100Mbps Auto-Negotiation and Auto MDI/MDI-X
• Flow control for Full Duplex operation and back pressure for Half Duplex operation
• 1536bytes packet size support
• Integrates address look-up engine, supporting 1K absolute MAC addresses
• Automatic address learning and address aging
• Desktop palm size
• LED indicators for PoE ready / activity and LINK / ACT
• One DC 56V power jack
Technical Specifications:
• Network Connector: 5-Port RJ-45 for 10/100Base-TX, auto MDI / MDIX
• PoE Inject Port: 4 ports with 802.3at / af PoE injector function (port 2 to port 5)
• PoE Standard: IEEE 802.3af Power over Ethernet / PSE, IEEE 802.3at Power over Ethernet Plus / PSE
• PoE Power Supply Type: Mid-Span
• Power Pin Assignment: 4/5(+), 7/8(-)
• PoE Power Output: Per Port 56V DC, 375mA. Max. 15.4 watts (IEEE 802.3af)
• Per Port: 56V DC, 375mA. Max. 30 watts (IEEE 802.3at)
• PoE Power Budget: 60 watts
• Number of 802.3af PD Class 0, 1, 2, 3 can be powered: 4
• Number of 802.3at PD Class 1, 2, 3 can be powered: 4
• Number of 802.3at PD Class 0, 4 can be powered: 2
• Standard Compliance: IEEE 802.3:Ethernet, IEEE 802.3u:Fast Ethernet, IEEE 802.3x:Flow Control, IEEE 802.3af:Power over Ethernet, IEEE 802.3at:High Power over Ethernet
• Switch Architecture: Store and Forward switch architecture
• MAC Address Table: 1K MAC address table with auto learning function
• Switch Fabric: 1Gbps
• Switch Throughput: 0.74Mpps @64Bytes
• Maximum Packet Size: 1536Bytes
• Flow Control: Back pressure for Half-Duplex. IEEE 802.3x Pause Frame for Full-Duplex
• Power Requirements: DC 56V, 1.5A.
• Power Consumption: Max.62 watts / 211.5 BTU
• Dimensions (W x D x H): 90 x 80 x 21 mm
• Weight: 172g
