Price (inc. VAT): 135.52 €
Ask for the balance
IP network camera FULL HD HDBW2300RP-VF
Features:
• 1/3” 3Megapixel progressive CMOS
• H.264 & MJPEG dual-stream encoding
• Max 20fps@3M(2048x1536) & 25/30fps@1080P(1920 x1080)
• DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
• 2.7~12mm varifocal lens
• Max IR LEDs Length 30m
• IP66, IK10, PoE
Technical Specifications:
Camera
• Image Sensor: 1/3” 3Megapixel progressive scan CMOS
• Effective Pixels: 2048(H)x1536(V)
• Scanning System: Progressive
• Electronic Shutter Speed: Auto/Manual, 1/3(4)~1/10000s
• Min. Illumination : 0. 01Lux/F1.4 (Color), 0Lux/F1.4(IR on)
• S/N Ratio: More than 50dB
• Video Output: N/A
Camera Features
• Max. IR LEDs Length: 30m
• Day/Night: Auto(ICR)/Color/B/W
• Backlight Compensation: BLC / HLC / DWDR
• White Balance: Auto/Manual
• Gain Control: Auto/Manual
• Noise Reduction: 3D
• Privacy Masking: Up to 4 areas
Lens
• Focal Length: 2.7mm~12mm
• Max Aperture: F1.4
• Focus Control: Manual Auto
• Angle of View: H: 92°~28°
• Lens Type: Manual/Fixed Iris
• Mount Type: Board-in Type
Video
• Compression: H.264/ H.264H/ MJPEG
• Resolution: 3M(2048x1536)/1080P(1920x1080)/1.3M(1280×960)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240)
• Frame Rate: Main Stream 3M(1 ~ 20fps)/1080P (1 ~ 25/30fps)
• Sub Stream: D1/CIF(1 ~ 25/30fps)
• Bit Rate: H.264H: 40K ~ 8192Kbps; MJPEG: 40K~16384Kbps
Audio
• Compression: N/A
• Interface: N/A
Network
• Ethernet: RJ-45 (10/100Base-T)
• Wi-Fi: N/A
• Protocol: IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
• Compatibility: ONVIF, PSIA, CGI
• Max. User Access: 20 users
• Smart Phone: iPhone, iPad, Android, Windows Phone
Auxiliary Interface
• Memory Slot: N/A
• RS485: N/A
• Alarm: N/A
• PIR Sensor Range: N/A
General
• Power Supply: DC12V, PoE (802.3af)
• Power Consumption: <4.5W
• Working Environment: -30°C~+60°C, Less than 95% RH
• Ingress Protection: IP66
• Vandal Resistance: IK10
• Dimensions: f122mm×89mm
• Weight: 0.5kg
