Features:

▪ 1/4” Progressive Scan EXview HAD CCD
▪ High resolution of 600TVL (Color), 650TVL (B/W)
▪ Min. illumination of 0.04/0.04/0.1Lux (Color), 0.01/0.005/0.01Lux (B/W)
▪ Powerful 18x optical zoom and 12x digital zoom
▪ WDR, Day/Night (ICR), DNR (3D/2D), Auto iris, Auto focus, AE, AWB, AGC, BLC
▪ Up to 24 privacy masking areas
▪ Max 400 °/s pan speed, 360° continuous pan rotation & auto flip with no blind spot monitor
▪ Up to 255 preset, 5 auto scan, 8 tour, 5 pattern
▪ Auto recognition of general protocols such as DH-SD, Pelco-P/D, and etc
▪ Speed setup according to the focal distance, auto rotation speed adjust in accordance with the lens zoom rate
▪ Auto restore to previous PTZ and lens status after power failure
▪ Time Task: Auto activation of Preset/Scan/Tour/ Pattern by preset-time
▪ Idle task function supported: Call preset/tour and etc operations after idle for the specified time (including the idle status after the system boots up)
▪ OSD and operation prompts of various languages
▪ Build-in 7/2 Chanel input/output
▪ Unique 3D positioning function
▪ IP67 all-environments protection, 4000V thunder-proof, auto constant temperature & anti-fog
▪ Easy installation with user-friendly designs

Technical Specifications:

▪ Image Sensor : 1/4” Progressive Scan EXview HAD CCD
▪ Effective Pixels: PAL: 752(H) x 582(V)
▪ Horizontal Resolution: 600TVL(Color), 650TVL(B/W)
▪ Min. Illumination: 0.04Lux/F1.4(Color), 0.01Lux/F1.4(B/W)
▪ Lens: 18x zoom f=4.1mm(wide) ~ 73.8mm(tele), F1.4 ~ F3.0
▪ Digital Zoom 12x
▪ Angle of View: 48°(wide) ~ 2.8°(tele)
▪ Close Focal Distance: 290mm(wide) ~ 800mm(Tele)
▪ Electronic Shutter: PAL: 1/3 ~ 1/10000 sec. (20 steps), NTSC: 1/4 ~ 1/10000 sec. (20 steps)
▪ WDR: ON/OFF/AUTO
▪ Day/Night: ICR, ON/OFF/AUTO
▪ 3D Noise Reduction: ON/OFF (level 5 to 1 / OFF, 6 steps)
▪ Gain: Auto/Manual/Max. Gain Limit (-3 dB to +28 dB, 2 dB steps)
▪ Exposure Control: Auto, Manual, Priority mode (shutter priority & iris priority), Bright, EV compensation, Slow AE
▪ BLC: ON/OFF
▪ White Balance: Auto, ATW, Indoor, Outdoor, Outdoor Auto, Sodium Vapor Lamp (fix/auto), One-push, Manual
▪ Picture Effects: E-Flip, Nega Art, Black & White, Mirror image, Color Enhancement
▪ S/N Ratio: More than 50 dB
▪ Privacy Masking: ON/OFF (up to 24 privacy masking areas)
▪ Video Output: BNC(1.0Vp-p / 75Ω), PAL
▪ Pan/Tilt Range: Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor
▪ Manual Control Speed: Horizontal: 0.1°~300°/s, Vertical: 0.1°~150°/s
▪ Preset Speed: Horizontal: 400°/s, Vertical: 180°/s
▪ Preset: 255
▪ PTZ Mode: 5 Auto Pattern, 8 Auto Tour, 5 auto scan
▪ 3D Positioning: Yes
▪ Speed Setup: Human-oriented focal Length/ speed adaptation
▪ Info Display: Time, Location, Dome title, Dome coordinates, Temperature, Alarm, and etc.
▪ Power up Action: Auto restore to previous PTZ and lens status after power failure
▪ Idle Motion: Activate preset/scan/tour/ patter if there is no command in the specified period.
▪ Time Task: Auto activation of Preset/Scan/Tour/ Pattern by preset-time
▪ Alarm: 7/2 alarm input/output, Triggering Preset/Tour/Pattern/Scan/On-off Output
▪ Remote Upgrade: Yes, RS485
▪ Protocol: DH-SD, Pelco-P/D, Auto recognition of general protocols
▪ Power Supply: AC 24V/3A(±10%)
▪ Power Consumption: 12W(Indoor), 50W(Outdoor, heater on)
▪ Working Temperature: -40ºC ~ 60ºC
▪ Working Humidity: <90%
▪ Protection Level: IP67, 4000V thunder, surge and wave protection
▪ Dimension: Φ222(mm) x 322(mm)
▪ Weight: 5.0kg
