Features:
• 640*512 VOx uncooled thermal sensor technology
• Athermalized Lens, Focus-free
• Support ROI, Motion Detection ,Color Palettes
• Built-in 2/1 alarm in/out
• Micro SD memory(Max 128G)
• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
• Tri-Mode for video output IP/HDCVI/Analog
• H.264&MJPEG dual-stream encoding
• IP66, PoE
Technical Specifications:
Thermal Camera
• Sensor Type Long Life,Uncooled VOx Microbolometer
• Effective Pixels 640(H) x 512(V)
• Pixel Size 17um
• Thermal Sensitivity <50mK@f/1.0
• Spectral range 7～14um
Lens
• Focal Length 7mm 13mm 19mm
• Focus Range Athermalized ,Focus-free
• Angle of View(H×V) 90° *69°Man (1.8m*0.5m)
• Detection:250m
• Recognition:60m
• Identification:40m
Angle of View(H×V) 45° *37°Man (1.8m*0.5m)
• Detection:450m
• Recognition:120m
• Identification:60m
Angle of View(H×V) 32° *26°Man (1.8m*0.5m)
• Detection:650m
• Recognition:180m
• Identification:80m
Angle of View(H×V) 90° *69° Vehicle (2.3m*2.3m)
• Detection:640m
• Recognition:170m
• Identification:70m
Angle of View(H×V) 45° *37° Vehicle (2.3m*2.3m)
• Detection:1300m
• Recognition:340m
• Identification:170m
Angle of View(H×V) 32° *26° Vehicle (2.3m*2.3m)
• Detection:2000m
• Recognition:500m
• Identification:250m
Camera Features
• Digital Zoom 24X
• Color Palettes 14(Whitehot/Blackhot/Ironrow/Icefire/FusionRainbowGlobowIconbow1Iconbow2 .etc)
• ROI Support, Custom areas
• Motion Detection Support
Video
• Compression H.264Main profile/H.264High profile/M-JPEG
• Frame Rate Main Stream 720P(1 ~ 25/30fps)(default)/ 1280*1024(1 ~ 25/30fps), Sub Stream 640*360(1 ~ 25/30fps) (default)/ 640*512(1 ~ 25/30fps)
• Bit Rate H.264: 448 ~8192Kbps
• Video Output IP/ Analog (HD-CVI Optional)
Smart Function
• Smart detection
• Tripwire
• Intrusion
• Perimeter Protection
• Object Detection(Person&Vehicle)
Audio
• Compression G.711a/G.711u(8K 16BIT）
• Interface 1 channel Out
Network
• Ethernet RJ-45 (10/100Base-T)
• Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
• Compatibility ONVIF PSIA CGI
• Max. User Access 20 users
• Smart Phone iPhone, iPad, Android, Windows Phone
Auxiliary Interface
• Memory Slot Micro SD, Max 128GB
• RS485 N/A
• Alarm 2/1 channel In/Out
• Audio 1 channel In
General
• Power Supply AC24V/DC12V/POE
• Power Consumption <6W
• Working Environment -40°C~+60°C, Less than 95% RH
• Ingress Protection IP66
• Dimensions 270 mm × 103mm× 97mm
• Weight 1.37kg
