Features:
• 128 channel standalone Network Video Recorder
• Support a wide range of the 3rd party IP cameras
• Up to 32 channel 1080P cameras realtime live view
• Up to 6-screen output: 6 HDMI sync output/1 VGA+5 HDMI sync output
•Support 16 hot-swappable SATA HDDs to better its expandability and flexibility
• Support multiple RAID mode such as RAID0, RAID1 and RAID5
•The latest Dahua UI adopted to make operations more human-oriented.
•Based on a multi-client system and supports up to 128 channel @D1, 64 channel @720P, 32 channel @1080P realtime recording
•Compatible with Dahua SDK and seamless integrated to other platforms
Technical Specifications:
• Main Processor: Intel® Core™ i7 Processors
• Operating System: Embedded LINUX
• Motherboard: Embedded Board (Support 7x24 operation)
• Memory: 4GB DDR3(up to 8GB)
• Case: Hot-dipped galvanized sheet steel(1.2mm thickened), High-precise aluminum alloy slide, Patented pull-out rack design
• Fan: Dual ball screw bearing fan, MTBF>100,000h, support replacement during operation
• Interface: Local GUI &WEB GUI
• Video Input: 128ch@D1/64ch@720P/32ch@1080P
• Transmission: 128ch@D1/64ch@720P/32ch@1080P
• Recording: 128ch@D1/64ch@720P/32ch@1080P
• Preview: 6ch@1080P/9ch@720P/36ch@D1
• Playback: 6ch@1080P/9ch@720P/36ch@D1
• Recording Resolution: 5M, 3M, 1080P, 720P, 960H, D1, CIF, QCIF, VGA
• Audio: 1ch input,1ch output, 1ch microphone
• Recording Mode: Manual, Schedule(Regular(Continuous), MD(Video detection: Motion detection, Camera blank, Video loss), Alarm), Stop
• Alarm Recording: Video loss, Camera blank, Motion detection, External alarm
• Backup Mode: Network download / USB HDD/USB CD&DVD-RW / eSATA Device
• Display Interface: 6 HDMI, 1 VGA
• Video Output: 6 HDMI, or 1ch VGA(or built-in LCD) and 5ch HDMI sync video output
• Multi-screen Display: The 1st screen: 1/4/6/8/9/16/32/64/128, The 2nd-6th screens: 4
• Privacy Masking: Four customized zones for privacy masking for each area
• Hard Disk: 16 SATA II s
• HDD Mode: Single, Raid 0, Raid 1, Raid 5. (Support global HDD Hot-standby)
• HDD Installation: Independent HDD rack, support hot swap
• Network Interface: 4 RJ-45 ports(10/100/1000M)
• Ethernet Port: 4 Ethernet ports joint working or 4 independent 1000M Ethernet ports
• Motion Detection: Zones: 396(22×18), Sensitivity: 1~6 (level 6 is highest)
• Alarm Input: 16ch, low level effective, green terminal interface
• Relay Output: 8ch, Relay contact(1A@24VDC), NO/NC programmable, green terminal interface
• Front cover: Support hot swap
• USB: 4 USB ports(2 on the front-panel, 2 on the rear panel)
• eSATA: 1 eSATA
• Power Supply: 100V-240Vac, 47-63Hz
• Power Consumption: <240W(Include HDD)
• Working Environment: 5C~40C
• Working Humidity: 10%~80% ( non-condensation)
• Dimension: 133mm*446mm*500mm(W×D×H)
• Weight: 35Kg
• Installation: Rack-mounted
