Features:
• Industrial level DID LCD panel, suitable for 7*24 continuous works.
• Ultra-narrow side LCD patchwork
• High contrast and high brightness greatly enhance the video layering, and present the details of the video.
• High fidelity digital processing, brilliant and vivid video.
• Built-in 3D COMB filter and 3D Noise Reduction
• Abundant interfaces, support video loop
• Built-in picture splicing function
• Infrared, RS232 double mode, supporting remote PC control
• Fan smart detection, OSD prompt.
• Brightness smart detection, power-saving
• Using Tamper-proof metal housing, no radiation
• Professional thermal design to extend equipment lifespan
• Built-in power, low energy consumption, ultra-quiet
• Fast stack installation, professional project design, supporting arc-shaped mounting
• Widely used in MCC(monitor command center), Dispatching Platform, Safety City
Technical Specifications:
• Diagonal: 46"(16:9)
• Type: S-PVA(FHD)
• Resolution: 1920×1080
• Dot Pitch: 0.53025(H)×0.53025(V)
• Physical seam: 5.7mm (Upper left:3.8 Lower right:1.9)
• Optical seam: 5.9mm
• Backlight: LED
• Brightness(Standard): 450 cd/㎡
• Contract: 3500:1
• Angle of view: 178°/178° (vertical / horizontal)
• Response Time(Grey Scale): 8ms
• Gamut(CIE1931): 72%
• Display Color: 16.7M/8bit
• Saturation: 92%
• Video Input: CVBS(BNC)×2
• PC Signal: VGA(D-Sub)×1
• Net Video Decode Signal（Optional）: RJ45，High definition H.264 video decoding signal
• Digital Signal: DVI×1 [1080P(1920×1080), downward compatible]
• HDMI×1 [1080P(1920×1080), downward compatible]
• Loop Out: CVBS(BNC)×2
• Consumption (Standard): 133W
• Consumption (Standby): ≤1W
• Power Supply: AC100-240V~(+/-10%),50/60 Hz
• Installation Mode (all optional): Modular Stacking/ Cabinet installation (Back up)
• Cooling System: Industrial Cooling Fan
• Control Mode: RS232 serial control，all way loop，infrared remote control
• Frame Color: Black
• Case Material: Metal
• Gross Weight (including Structural parts): 22.5kg
• Unit Dimension(mm): 1024×579×245
• Display Area(mm): 1018×573
• Package Dimension (mm): 1235×820×460
• MTBF: 50,000 hours
• Work Environment: Temperature：0℃~50℃
• Humidity：20%~95%
• Altitude：0-23000ft
• Storage Environment: Temperature：-25℃~70℃
• Humidity：60%~75%
• Altitude：0-43000ft
• Features: Double-sided physical seam 5.7mm
• Build-in industrial level fan
• High and low current are installed respectively
• Infrared remote control
• Remote PC centralized control
