Features:
• RS-485 protocol
• Default IC (Mifare) card
• Support card, password
• All-metal buttons with blue backlight
• Watch dog function ensure device free from halting
• Beep and indicator
• Surface mounted installation
• Tamper alarm and vandal-proof
Technical Specifications:
System
• Main Processor 8 Bit
Read
• Read Format 13.56MHz(Mifare)/125KHz(EM, Optional)
• Read Range 3-5cm (max.)
• Response time <0.1s
Function
• Tamper Alarm Yes
Interface
• To Controller RS485
General
• Keypad 12Key(0-9,*,#), number key 5 is a braille button
• LCD Display Blue backlight
• Beep Tone Buzzer
• Ingress protection IK08, IP55
• Power Supply 9-15VDC/100mA
• Working Environment -30?-+60?
• Working Humidity =95%
• Dimension(W× D× H) 110mm*85mm*26mm
• Weight 0.5Kg
