Features:
• RS-485 protocol
• Default IC (Mifare) card
• Blue backlight
• Watch dog function ensure device free from halting
• Beep and indicator
• Surface mounted installation
Technical Specifications:
System
• Main Processor 8 Bit
Read
• Read Format 13.56MHz(Mifare)/125KHz(EM, Optional)
• Read Range 6-8cm (max.)
• Response time <0.1s
Function
• Tamper Alarm Yes
Interface
• To Controller RS485 Wiegand
Genreal
• LCD Display Blue backlight
• Beep Tone Buzzer
• Ingress protection IP55
• Power Supply 9-15VDC/100mA
• Working Environment -30?-+60?
• Working Humidity =95%
• Dimension(W× D× H) 135mm*86mm*12mm
• Weight 0.25Kg
