Features:
• Support 100,000 valid cards & 300,000 records
• Support multiple cards
• Support card, password, fingerprint and combination
• TCP/IP or RS-485 interface to PC
• Wiegand or RS-485 interface to readers(2/4 door)
• Door time out alarm, intrusion alarm, duress alarm and tamper alarm
• Anti-pass back, multi-door interlock, multi-card open
• Support 128 efficient time and holiday schedules
• Watch dog function ensure device free from halting
• Surface mounted installation
Technical Specifications:
System
• Main Processor 32 Bit
• Memory 16M(32M External)
Input/Output Ports
• Input Inputs x 9 ( door sensor x 4, exit button x 4, alarm x 1)
• Output Relay x 5(door lock x 4, alarm x 1 )
• Reader Reader x 4
Capacity
• Cardholders/Events 100,000/150,000
Function
• User Management General, VIP, Guest, Patrol, Black list, Force
• Alarm Function Door time out alarm, Intrusion alarm, Duress alarm, Tamper alarm
• Schedule Setting Support 128 groups of schedule, 128 groups of period and 128 groups of holiday period
Interface
• To PC RJ45(10/100M)/RS485
• To Reader Wiegand/ RS485
Genreal
• RTC Yes
• Ingress protection IP55
• Power Supply 9-15DC/500mA
• Internal Battery 1204C Support
• Working Environment -30?-+60?
• Working Humidity =95%
• Dimension(W× D× H) 210*98*51mm
• Weight 0.5Kg
